Whistle, Bell Guitar Evaluation Board User Guide Combined Evaluation Board
MAN-EVLBRD-WHI-BEL-GUI (Ver. 1.401)
64
Pin Signal Function
12 IN3 General input 3
13 IN4 General input 4
14 IN5 General input 5
15 IN6 General input 6
16 SUPRET Supply return
17 +5V_EXT Non-isolated +5V Supply Voltage
18 AN1- Analog input 1 (negative)
19 OUTP4 Programmable output 4
20 OUTP3 Programmable output 3
21 OUTP2 Programmable output 2
22 OUTP1 Programmable output 1
23 -VDO Input of an external +24V RETURN
24 -VDO Input of an external +24V RETURN
25 VDO Input of an external +24V, for supplying the LED
drivers and Brake.
Can be either isolated or not – depending on the
user’s application requirements.
26 VDO Input of an external +24V, for supplying the LED
drivers and Brake.
Can be either isolated or not – depending on the
user’s application requirements.
Table 2-9: General I/O Port and Cable - Pin Assignments
