.9 Bell
This section explains how to connect the Bell to the Evaluation Board, and provides details
about all the connectors.
.9.1 Connecting the Bell to the Evaluation Board
Each Bell has 53 pins; therefore, great care should be taken aligning its pins with the
sockets on the board when assembling. Push the Bell into the Evaluation Board firmly and
evenly.
Figure 8: Assembling the Bell on the Evaluation Board
H1
H2
H4
H5
M 2½ x 5 mm
Spring washers
4 spacers
recommended
M 2½ x 21
mm
