Whistle, Bell Guitar Evaluation Board User Guide
Safety Information
MAN-EVLBRD-WHI-BEL-GUI (Ver. 1.401)
2
Notice
This guide is delivered subject to the following conditions and restrictions:
This guide contains proprietary information belonging to Elmo Motion Control Ltd.
Such information is supplied solely for the purpose of assisting users of the Whistle,
Bell or Guitar servo drives in their evaluation and testing.
The text and graphics included in this manual are for the purpose of illustration and
reference only. The specifications on which they are based are subject to change
without notice.
Elmo Motion Control and the Elmo Motion Control logo are trademarks of Elmo
Motion Control Ltd.
Information in this document is subject to change without notice.
Document No. MAN-EVLBRD-WHI-BEL-GUI.pdf
Copyright 2014
Elmo Motion Control Ltd.
All rights reserved.
Evaluation Board Catalog Number:
EVA-WHI/GUI/BEL
Related Products:
Product
Catalog Number
Installation Guide
Whistle
WHI-
A
XX-YYY
R
MAN-WHISIG (available on the Website)
Bell
BEL-
A
XX-YYY
E
MAN-BELIG
Guitar
GUI-
AR
XX-YYY
R
MAN-GUIIG (available on the Website)
Revision History:
Version
Release Date Changes/Remarks
Ver 1.4
May 2010
MTCR 04-010-01: Update to Table 2-4.
Ver 1.3
July 2009
MTCR 03-009-46: Tables 2-1, 2-3: Changes in DC Motor Cable column.
Table 2-2: Motor Power section: AC Motor Cable column removed. DC Motor
Cable changed to Stepper Motor.
Ver 1.2
February 2009
Table 2-9: Pins 10-15 “General input return” changed to “General input”.
Ver 1.1
October 2008
Updates to section 2.9.3 for differential pulse-and-direction outputs
Ver. 1.0
August 2008
Initial release
Elmo Motion Control Ltd.
64 Gissin St., P.O. Box 463
Petach Tikva 49103
Israel
Tel: +972 (3) 929-2300
Fax: +972 (3) 929-2322
Elmo Motion Control Inc.
42 Technology Way
Nashua, NH 03060
USA
Tel: +1 (603) 821-9979
Fax: +1 (603) 821-9943
Elmo Motion Control GmbH
Steinkirchring 1
D-78056, Villingen-Schwenningen
Germany
Tel: +49 (0) 7720-85 77 60
Fax: +49 (0) 7720-85 77 70
www.elmomc.com
