Whistle, Bell Guitar Evaluation Board User Guide Combined Evaluation Board
MAN-EVLBRD-WHI-BEL-GUI (Ver. 1.401)
10
Combined Evaluation Board
.6 Introduction
The combined Evaluation Board has the following advantages:
1. It can evaluate three different types of drives:
• Whistle
• Bell
• Guitar
2. D-type, RJ and Phoenix connectors can be easily connected to the Evaluation Board.
3. The Evaluation Board has the following additional features:
• Main buffered output
• Differential ports for auxiliary feedback input/output
• Powerful digital outputs (I
out
≤ 250 mA)
• Flexibility in digital inputs (from 5 V ≤ V
in
≤ 24 V)
• Powerful output for the brake (separate output via a Phoenix connector)
• Support for CAN Communication in daisy chain mode
• Visual indication of all the digital outputs and the Brake.
• Intelligent power supply coupling.
.7 Before You Begin
.7.1 Site Requirements
You can guarantee the safe operation of the Evaluation Board by ensuring that it is
installed in an appropriate environment.
Feature Value
Ambient operating temperature 0 °C to 40 °C (32 °F to 104 °F)
Maximum operating altitude 2,000 m (6562 feet)
Maximum relative humidity 90% non-condensing
Operating area atmosphere No flammable gases or vapors permitted in area
