The Evaluation Board dissipates its heat by natural convection.
The maximum operating ambient temperature of 0 °C to 40 °C
(32 °F to 104° F) must not be exceeded. Refer to the Heat
Dissipation section of the relevant installation guide for further
details.
.7.2 Unpacking the Evaluation Board
Before you begin working with the Evaluation Board system, verify that you have all of its
components, as follows:

The Evaluation Board
 This document – the Whistle, Bell & Guitar Evaluation Board User Guide. (You can
download the PDF version from the Elmo web site.)
 CBL-EVAUNIKIT01 (cable kit)
 ACC-KIT-BEL/WHI01 (spacers and screws)
 ACC-KIT-GUI01 (spacers and screws)
 ACC-TRM-01 (RJ-45 terminator connector)
The Evaluation Board is shipped in a cardboard box with styrofoam protection.
To unpack the Evaluation Board:
1. Carefully remove the Evaluation Board from the box and the Styrofoam.
2. Check the Evaluation Board to ensure that there is no visible damage to the instrument. If
any damage has occurred, report it immediately to the carrier that delivered your drive.
3. To ensure that the Evaluation Board you have unpacked is the appropriate type for your
requirements, locate the part number sticker on the side of the Evaluation Board. It looks
like this:
4.
