12 figure 13—detectro terminal block – Det-Tronics C7052J UV/IR Flame Detector used with R7494, R7495 Controller User Manual
Page 12
12
Figure 13—Detectro Terminal Block
D0947
+
24 VDC (A)
OUTPUT SIGNAL (B)
CIRCUIT GND (C)
oi SIGNAL (D)
EARTH GND
Figure 12—C7052J Detector Part Identification
F0946
JUNCTION BOX
JUNCTION BOX COVER
MOUNTING PIN
IR TEST LAMPS (2)
O-RING
IR SENSOR HOUSING
IR oi RING
INDEX PIN
UV SENSOR MODULE
O-RING
UV TEST LAMP OPENING
UV SENSOR HOUSING
UV oi RING
IR SENSOR MODULE
UV TERMINAL BLOCK
