8.1.12. Enable Page Default Values
Menu Item Display Default Range Setting
Profiles Enable Profile 1-8 Yes Yes or No
Autostart Enable Auto Start No Yes or No 33
PID Enable PID Yes Yes or No
Control Enable Control No Yes or No
Communication Enable Communication No Yes or No 33
Real Time Clock Enable Clock No Yes or No 33
Relay outputs Enable Relay 1-4 No Yes or No 33
Test Enable Test No Yes or No
Zone Calibration Enable Zone Cal No Yes or No
Sensor Calibration Enable Sensor Cal No Yes or No
Setpoint lower limit Enable SPLowerLim 20°C -73°C to 759°C (-100°F to
1399°F)
Setpoint upper limit Enable SPUpperLim 260°C -73°C to 760°C (-100°F to
1400°F)
High limit overhead Enable HiLimOH 5°C 3 to 11°C (5 to 20°F) 34
Password level 1 Enable Password 1 1 0 to 999
Password level 2 Enable Password 2 2 0 to 999
Manual/Timer mode
setpoint change Enable SPChange Yes Yes or No
Analog Output Type Enable Analog Type Proc Ctrl or Proc
33 If the controller does not have this feature, No is the only option.
34 Maximum high limit setpoint (MaxHiLimSP) = SPUpperLim + HiLimOH. Minimum high limit
setpoint (MinHiLimSP) = SPLowerLim + HiLimOH.
