A SSEMBLY & S ETUP Protocol Plus Owner’s Manual
20 Version 2
Copyright © 2010 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
Table 1. MRC 5000 Settings.
Parameter Code
Degrees C Degrees F
Inps 18 18
Icor 0 0
diSP On On
dPOS 0 0
EUU
1
400 752
EUL
1
0 32
ChUP 400 800
2
ChLO 0 0
DFF 1 1
1
These values must match the settings RetOutLo and RetOutHi on the Protocol Plus Control page. For
example, if RetOutLo is 32, EUL must read 32.
2 Change 0-400 chart paper to 0-800 chart paper. Depending on the equipment used, 0-600 paper may be
used if the maximum temperature is 500 degrees F.
