Protocol Plus Owner’s Manual O PERATION
Version 2 35
Copyright © 2010 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
Menu Item Display Description Range
Power fail
recovery Control PwrFRec Controls response to loss of
power
Stop, Restart, Hold, Resume
Recovery
time limit Control PFRTime Control aborts to Stopped
mode if power is lost for time
period longer then set value
00m00s to 99m59s
Powerup
start
enable ControlPwrUpStrt Allows mode to automatically
start when power is first
applied
Disable, Enable
Powerup
Start Mode Control StrtMode Operating mode for powerup
start Off, Manual, Timer, Pro-1 to Pro-8
Hysteresis Control
Hysteresis Hysteresis for all alarms and
temperature events 1°C to 56°C (1°F to 100°F)
Process
out low Control
RetOutLo Process value for retransmit
output = 1VDC -73°C to 760°C (-100°F to
1400°F)
Process
out high Control RetOutHi Process value for retransmit
output = 5VDC
-73°C to 760°C (-100°F to
1400°F)
Time scale Control
TimeScale Time scale setting for program
and timer mode
7
hh:mm or mm:ss
Key press
beep Control KeyBeep Internal beeper sounds when
key is pressed On or Off
End of
cycle beep Control
EOCBeep Internal beeper sounds at end
of cycle On or Off
Alarm beep Control
AlarmBeep
Internal beeper sounds for
alarms On or Off
5.6.8. Setting up the Communication Page
The Communication Page contains parameters for the communications feature. Table 7
shows the menu items available.
5.6.8.1. Access Communication Page
1. Enter Setup Mode.
2. Press
Page until Communication displays.
3. Press Menu .
O
If the display does not change, the controller does not have the
communication board installed.
4. Change each parameter by pressing
Menu until the desired parameter is displayed,
and then press
▲ or ▼ to change the value.
7 Power fail recovery time limit is always MM:SS regardless of time scale setting
