Protocol Plus Owner’s Manual A PPENDICES
Version 2 53
Copyright © 2010 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
8.1.9. Test Page Default Values
Menu Item Display Default Range Setting
Heater output Test HeatOut Off On
High limit relay Test HiLimOut Off On
Relay 1 output Test Rly1 Out Off On
Relay 2 output Test Rly2 Out Off On
Relay 3 output Test Rly3 Out Off On
Relay 4 output Test Rly4 Out Off On
High Limit Sensor Test HL Temp (sensor reading)
8.1.10. Zone Cal Page Default Values
Menu Item Display Default Range Setting
Zone 1 actual Zone Cal Zone1Act 38°C -73°C to 760°C (-100°F to
1400°F)
Zone1 displayed Zone Cal Zone1Dis 38°C -73°C to 760°C (-100°F to
1400°F)
Zone 2 actual Zone Cal Zone2Act 260°C -73°C to 760°C (-100°F to
1400°F)
Zone2 displayed Zone Cal Zone2Dis 260°C -73°C to 760°C (-100°F to
1400°F)
Factory
calibration
31
Zone Cal FactCal Ready Ready or Done (push- key)
8.1.11. Sensor Cal Page Default Values
Menu Item Display Default Range Setting
Control Sensor
Cal Ctrl Sens 0F
Ctrl Sens 1000F
Ctrl Sens Done -100°F
1400°F
Done -100 to 1400°F
-100 to 1400°F
(read only)
HiLim Sensor Cal HL Sens 0F
HL Sens 1000F
HL Sens Done -100°F
1400°F
Done -100 to 1400°F
-100 to 1400°F
(read only)
Retransmit Cal RetCalLo XXXX
32
32
RetCalHi XXXX
0
4096 0 to 4096
0 to 4096
31 Use only when no calibration instrument is available.
32 The “RetCalLo” and “RetCalHi” values are only change indicators. The actual value is not meaningful.
