4.2. MRC5000 Setup (Optional)
O
Refer to instructions provided recorder manufacturer for more
specific installation notes.
Temperature is retransmitted to the MRC5000 recorder from the controller. Set up the
recorder by:
1. Ensure hardware jumper JU1 is in place for the 5 VDC setting (Refer to MRC5000
Manual included).
2. Move Mode to PROG/TEST/CAL to display Prog .
3. Press
▼ twice to display
Inps . Move to each Parameter Code using
▼or ▲. Adjust
each Parameter Code using the settings in Table 1.
4. After adjusting all settings, move Mode to RUN . Display on both the Recorder and
controller should read the same.
Figure 6. Protocol Plus Wiring Diagram.
