5.4. Profile Mode
1. Press Select until Profile is displayed. None may display if a profile has not been
selected or no profiles have been entered.
2. Press
▲ or ▼ to display the desired profile.
3. Start Profile Mode by pressing Run .
The display will change from Stop to Run and show segment time remaining,
Temperature Setpoint, Profile #, and the current segment number. To return to Stopped
Mode, press
Stop .
O
Press Run/Hold while in Profile Mode puts the control into Hold.
Press Run/Hold again to continue in Profile Mode. The Profile
LED flashes to indicate Hold status.
4. To advance to the next segment while running a profile, press Select and
▲ at the
same time.
If
Link To is set to Standby in the Program Page, at the End of Program/Profile,
1. Cycle Complete LED indication goes ON.
2. Controller beeps if End of Cycle beep is enabled.
3. Heater/control output keeps controlling oven temperature at last Soak setpoint.
4. All events programmed (if relay cards are installed and programmed as an event) for
the last Soak Segment stays active.
O
Ramping down too fast may cause the high limit relay to trip
unexpectedly if the high limit band feature is used. Avoid
tripping the high limit relay by using a separate cooling profile
(one that does not use the high limit band) and then linking to
that profile to perform rapid cooling.
5.5. Auto Start Mode
Auto Start allows the operator to start Manual, Timer, or Profile modes automatically at a
preset time and day. See Setting Up Auto Start (Section 5.6.5) for the time, day, and
operating mode settings.
O
If AutoStart is set to No in the Setup menu, AutoStart will not
display on the main Menu. If AutoStart is set to Yes in the Setup
menu, AutoStart will display on the main Menu.
