Protocol Plus Owner’s Manual A PPENDICES
Version 2 47
Copyright © 2010 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
8. Appendices
8.1. Quick Reference and Default Values
8.1.1. Program Page Default Values
Table 16. Program Page Default Values.
Menu Item Display Default Range Setting
Ramp Time Seg
20
Pro-1 Seg-1 Ramp Time 00:00 00m00s to 99h59s
Event 1 Set Value Pro-1 Seg-1 Ramp Event Off Off, On
Event 2 Set Value Pro-1 Seg-1 Ramp Event Off Off, On
Event 3 Set Value Pro-1 Seg-1 Ramp Event Off Off, On
Event 4 Set Value Pro-1 Seg-1 Ramp Event Off Off, On
Soak Temp Seg Pro-1 Seg 1 Soak Temp 68°F SPLowerLim to
SPUpperLim
21
Soak Time Seg Pro-1 Seg 1 Soak Time 00:00 00m00s to 99h59s
Event 1 Set Value Pro-1 Seg-1 Soak Event Off Off, On
Event 2 Set Value Pro-1 Seg-1 Soak Event Off Off, On
Event 3 Set Value Pro-1 Seg-1 Soak Event Off Off, On
Event 4 Set Value Pro-1 Seg-1 Soak Event Off Off, On
(repeat for segments 2-8)
High Limit Setpoint Pro-1 Hi-Lim SP Max
HiLimSP MinHiLimSP to
MaxHiLimSP,
21
Band
22
Loop From Pro-1 Loop From XX No No, Seg-1 to Seg-8
Loop To Pro-1 Loop To XX No No, Seg-1 to Seg-8
Loop Count Pro-1 Loop Number 0 0 to 99
Profile Link Pro-1 Link To XX Stop Standby 23 , Stop,
Hold, Pro-1 to Pro-8
Guaranteed Soak Pro-1 Guar Band Off Off, 1 to 778°C
(1400°F)
(repeat for profiles 2-8)
20
Cycle Complete LED indication goes ON.
21
See Enable Page (5.6.11)
22
Band value is set on Control Page (5.6.7)
23 If Standby: (1) Cycle Complete LED indication goes ON. (2) Controller beeps if End Of Cycle beep is
enabled. (3) Heater/control output keeps controlling oven temperature at last Soak setpoint. (4) All events
programmed (if relay cards installed and programmed as an event) for the last Soak Segment stays active.
