WEB BROWSER-BASED CONFIGURATION
118
User Name and Password. The RAID controller default User Name
is “admin” and the Password is “0000”. After entering the user
name and password, press Enter key to access the McRAID stor-
age manager.
• Start-up McRAID Storage Manager from Linux/
FreeBSD/Solaris/Mac Local Administration
To configure the internal 6Gb/s SATA RAID controller. You need
to know its IP address. You can find the IP address assigned by
the Archttp proxy server installation:Binding IP:[X.X.X.X] and
controller listen port.
(1). You can click the individual adapter icon located on left
column of the “Archttp Configurations” screen or Launch your
McRAID storage manager by entering http://[Computer IP
Address]:[Port Number] in the web browser.
(2). When connection is established, the "System Login" screen
appears. The 6Gb/s SATA RAID controller default User Name is
“admin” and the Password is “0000”.
• Start-up McRAID Storage Manager Through Ether-
net Port (Out-of-Band)
Areca now offers an alternative means of communication for the
PCIe RAID controller – web browser-based McRAID storage man-
ager program. User can access the built-in configuration without
needing system starting up running the ArcHttp proxy sever.
The web browser-based McRAID storage manager program is an
HTML-based application, which utilizes the browser installed on
your remote system.
To ensure proper communications between the PCIe RAID con-
troller and web browser-based McRAID storage manager, Please
connect the RAID controller LAN port to any LAN switch port. The
controller has embedded the TCP/IP & Web Browser-based RAID
manager in the firmware. User can remote manage the RAID
controller without adding any user specific software (platform
independent) via standard web browsers directly connected to the
10/100Mbit RJ45 LAN port.
