APPENDIX
170
C-3-1 Using ArcHttp
The HTTP management software (Archttp) runs as a service or
daemon, and has it automatically start the proxy for all control-
lers found. This way the controller can be managed remotely
without having to sign in the server. The Archttp has also inte-
grated the ability of sending SNMP trap. Please reference the
manual Chapter 3 “ArcHttp Proxy Server Installation” section to
install and setup its configuration.
To enable the controller to send the SNMP traps to client SNMP
manager using the IP address assigned to the operating system,
such as Net-SNMP manager, you can simply use the SNMP
function on the ArcHttp proxy server utility. To enable the RAID
controller SNMP traps sending function, configure the “SNMP
Traps Configuration” options on the "ArcHTTP Configurations".
The Archttp proxy only provides one direction to send the trap to
the SNMP manager without needing to install the SNMP extension
agent on the host. For detailed information on using Archttp proxy
server utility to send the SNMP traps, please see "SNMP Traps
Configuration" section on 5.6 "Archttp Configuration".
If SNMP manager requests to query the SNMP information from
RAID controller, please refer the C-3-2 section - Using Onboard
NIC and C-3-3 section - Using In-band PCIe+ SNMP extension
agent.
C-3-2 Using Onboard NIC Installation
By using the built-in LAN port on the RAID controller- RAID con-
troller using built-in LAN interface. You can use the browser-based
manager or CLI SNMP configuration to setup the firmware-based
SNMP configuration. The following screen is the firmware-embed-
ded SNMP configuration setup screen using browser-based man-
ager:
To launch the above browser-based RAID controller SNMP func-
tion, click on the “System Controls” link. The “System Controls”
menu will show available items. Select the “SNMP Configuration”
item. The firmware-embedded SNMP agent manager monitors all
system events and the SNMP function becomes functional with no
agent software required.
