ARCHTTP PROXY SERVER INSTALLATION
114
When you open the SNMP traps configuration page, you will see the
following settings:
(1). SNMP Trap Configurations
Enter the SNMP trap IP address.
(2). SNMP System Configurations
Community name acts as a password to screen accesses to the
SNMP agent of a particular network device. Type the community
names of the SNMP agent in this field. Before access is granted to
a request station, this station must incorporate a valid community
name into its request; otherwise, the SNMP agent will deny access
to the system. Most network devices use “public” as default of their
community names. This value is case-sensitive.
(3). SNMP Trap Notification Configurations
Before the client side SNMP manager application accepts the 6Gb/
s SATA RAID controller traps, it is necessary to integrate the MIB
into the management application’s database of events and status
indicator codes. This process is known as compiling the MIB into
the application. This process is highly vendor-specific and should be
well-covered in the User’s Guide of your SNMP application. Ensure
the compilation process successfully integrates the contents of the
areca_SATA.mib file into the traps database. Please refer to Appen-
dix C of “ SNMP Operation & Installation”. The MIBs file resides at:
\packages\SNMP_MIBs on the software CD.
Note:
Event Notification Table refer to Appendix D.
After you confirm and submit configurations, you can use
"Generate Test Event" feature to make sure these settings are
correct.
• Rescan Device Configuration:
Let's assume you've put all Areca RAID adapters to a system.
The Archttp scans the RAID adapters on the system and create
an individual adapter icon located on left column of the Archttp
Configurations screen. This adapter icon is for user to launch web
browser RAID manager. If there is any RAID adapter missed on the
system start-up, you can use the "Rescan Device" function. The
