Operating manual, Left-hand tool shown – BAND-IT Shield-Lok Clamp User Manual
Page 7
SL4099 Shield-Lok™
Shield-Lok™ Tool Pack
Clamp
www.BAND-IT-IDEX.com
Document # P07687 Rev. E
© Copyright
BAND-IT-IDEX, Inc. 2012
All rights reserved
Page 7
BAND-IT-IDEX, Inc.
A Unit of IDEX Corporation
4799 Dahlia Street
Denver, CO 80216-3070 USA
P: 1-800-525-0758
F: 1-800-624-3925
Operating Manual
SL4000 Tool
Specifications
Clamp Type
BAND-IT ½” Shield-Lok™ Clamps
Powered Drill, Milwaukee, model 2410
Voltage
12VDC Battery
Cut Off
Manually Activated Lever
Tension System
Winding Mandrel, Gear Reduction System, Torque Limiter
Weight
4.1 Kg (9 Lbs)
Battery Charger
Milwaukee, 12VDC output, 120VAC 60Hz input
Left-hand tool shown
