Operating manual – BAND-IT Shield-Lok Clamp User Manual
Page 10
SL4099 Shield-Lok™
Shield-Lok™ Tool Pack
Clamp
www.BAND-IT-IDEX.com
Document # P07687 Rev. E
© Copyright
BAND-IT-IDEX, Inc. 2012
All rights reserved
Page 10
BAND-IT-IDEX, Inc.
A Unit of IDEX Corporation
4799 Dahlia Street
Denver, CO 80216-3070 USA
P: 1-800-525-0758
F: 1-800-624-3925
Operating Manual
Locking arm of blade must fit into buckle opening between layers of
band
Buckle orientation with respect to cut-off head during clamp installation
Locking arm
Top of buckle
Blade
Top of buckle
Locking arm
Blade
