background image

SL4099 Shield-Lok™

Shield-Lok™ Tool Pack

Clamp

www.BAND-IT-IDEX.com

Document # P07687 Rev. E

© Copyright

BAND-IT-IDEX, Inc. 2012

All rights reserved

Page 15

BAND-IT-IDEX, Inc.
A Unit of IDEX Corporation
4799 Dahlia Street
Denver, CO 80216-3070 USA
P: 1-800-525-0758
F: 1-800-624-3925

Operating Manual

Troubleshooting Guide

This tool is not to be adjusted or serviced by the user.

Observed

Problem

Possible Cause

Solution

When activating

cut off handle,

band does not cut

Tension not reached

Return to BAND-IT for repair

Shear plate dull

Retrigger tool to break band, service shear plate

Rotate or replace shear plate (page 13)

Band breaks

before cut off

Excess band tension

Return to BAND-IT for repair

Lock does not

form under

buckle

Excess wear on blade

Return to BAND-IT for repair

Drill will not

reach required

torque

Dead battery

Change battery

Clamp not tight

on tube and

shield

Clutch not fully engaged

Retrigger tool to set clutch and continue to tighten
clamp

Bad drill

Return to BAND-IT for repair

Winding mandrel

will not turn

when drill is

activated

Gear release lever not in proper
location

Check gear release lever on top of gearbox housing

Cut-off handle

loose

Broken coil pin

Replace coin pin per instructions (page 14)
