BAND-IT Gripper Installation User Manual
Gripper installation instructions
Gripper Installation Instructions:
1. Remove gripper. Align gripper pin
hole with notch in tool frame. Using a
punch and hammer, punch pin out of
slide block.
2. Using a wire brush, clean any
foreign matter from teeth of new
gripper.
3. Replace pin. Gripper spring must be
seated in tension screw hole. Align
gripper hole with slide block hole, insert
pin in hole and hammer pin in place.
P01899 REV. -
Gripper Installation Instructions:
1. Remove gripper. Align gripper pin
hole with notch in tool frame. Using a
punch and hammer, punch pin out of
slide block.
2. Using a wire brush, clean any
foreign matter from teeth of new
gripper.
3. Replace pin. Gripper spring must be
seated in tension screw hole. Align
gripper hole with slide block hole, insert
pin in hole and hammer pin in place.
P01899 REV. -
Gripper Installation Instructions:
1. Remove gripper. Align gripper pin
hole with notch in tool frame. Using a
punch and hammer, punch pin out of
slide block.
2. Using a wire brush, clean any
foreign matter from teeth of new
gripper.
3. Replace pin. Gripper spring must be
seated in tension screw hole. Align
gripper hole with slide block hole, insert
pin in hole and hammer pin in place.
P01899 REV. -
