12. Specifications
137 AirLive WHA-5500CPE User’s Manual
12.2 Radio Specifications
12.2.1 Frequency Band
„ 5.15 to 5.25GHz: U-NII Low and ETSI Band1
„ 5.25 to 5.35GHz: U-NII Mid and ETSI Band2
„ 5.47 to 5.725GHz: U-NII World Wide and ETSI Band3
„ 5.745 to 5.825GHz, U-NII Upper Band
12.2.2 Rate and Modulation
„ Data Rate : 6, 9, 12, 18, 24, 36, 48, 54Mbps
„ Modulation: Orthogonal Frequency Division Multiplexing (OFDM)
12.2.3 TX Output Power
„ 54 Mbps @ 17 dBm
„ 48 Mbps @ 18 dBm
„ 36 Mbps @ 19 dBm
„ 6, 9, 12, 18, 24 Mbps @ 20 dBm
12.2.4 Receiver Sensitivity
„ 54Mbps@-71 dBm
„ 12Mbps@-88 dBm
„ 6Mbps@-90
dBm
12.2.5 Supported WLAN Mode
„ 11a mode
„ SuperA without Turbo
„ SuperA with Dynamic Turbo
„ SuperA with Static Turbo
