Gateway Control
This group helps:
Monitor the current statuses of the GSM gateway components;
Check and set the GSM gateway licence;
View and save LOG files and CDR.
Firmware / Licence
This window provides information on the gateway licensing, firmware and bootware
versions and Ethernet interface MAC address. Use the web interface to download
a new
licence via Management–>Licence.
Firmware version – current firmware version of the gateway connected.
Bootware version – current bootware version of the gateway connected.
Firmware version of VoIP board –
current firmware version of the VoIP board
connected.
MAC address – Ethernet interface MAC address of the gateway connected.
– MAC address of VoIP board Ethernet interface MAC address of the VoIP
. board connected
CPU serial number – GSM gateway serial number in the format
M202–xxxxxxxxxx
Active: licensed protocols:
SIP – SIP support.
G729 – G.729ab voice codec support.
TUN – GSM–CSD remote supervision support.
DSS1 – ISDN BRI DSS1 protocol support.
MONI – ISDN monitoring support.
SMSU – count of SMS users.
SMPP support. SMSS –
SMS@email support. SMSE –
SMS via web support. SMSW –
SNMP monitoring support. SNMP –
Gateway limitation – gateway operation time (licence limitation if any).
Licence status – current licence status (unblocked/blocked).
Caution
When the licence code expires, the licence–based protocols will
be locked!
Networks – displays the list of allowed/disallowed GSM/UMTS networks.
Caution
Upon the dealer's request, the gateway may contain blocking of
certain GSM/UMTS networks. This state is indicated by a red
shining Ch 1 / Ch 2 LED on the GSM/UMTS board. The GSM
module diagnostic window displays the „netw–err status.
Contact your dealer for more information please.
