22

S

E C T I O N

6

Tension drive belt (replace if

necessary).

Refill reservoir. Purge air from

transmission if necessary.

Drain fluid from reservoir and

unit, replace filter element,

and refill with new fluid.

Check relief pressure in sys-

tem with a pressure gauge

rated to 2500 psi (system set

by factory at 1750 psi).

Repair or reconnect control

linkage.

Repair drive (replace broken

belt, repair sheared key, re-

pair splined coupling, etc.).

Refill reservoir. Purge air from

transmission.

Symptom

Will not attain normal feed rate.

Will not feed when control arm

is moved.

Feed rate is sluggish under

load.

Hydraulic Feed will not pull in

logs over 4" in diameter, or

continuously stalls or stops.

Probable Cause

Engine not operating at cor-

rect speed.

Control linkage damaged or

binding.

Bypass valve stuck partially

open. (Problem in one direc-

tion only.)

Control linkage damaged or

not connected.

Drive between engine and

pump damaged.

Pump low on fluid.

Loose drive belt between

engine and pump.

Pump low on fluid.

Large amount of water in hy-

draulic fluid (evaporates when

hot, resulting in low fluid level).

Hydraulic system overloading

and causing system to go

over relief.

Suggested Remedy

Repair engine governor.

Repair control linkage.

Repair bypass valve.

Remove foreign material from

valve.

6.2 Hydrostatic Pump Troubleshooting

Before servicing or
repairing any of the
hydrostatic feed
components (pump,
motor, and/or relief
valve), contact your
dealer or factory
service department.
Warranty on these
items may be void
without prior
authorization.

Caution: Hydraulic
systems contain fluid

under high pressure. Never
check for leaks with your
hands. Relieve pressure before
disconnecting any hydraulic
lines.
