Maintenance
FemtoJet
® 4i
English (EN)
42
8.1.2 Inserting the o-rings and the sealing washer
8.2 Replacing the sealing in the adapter for Femtotips
You must replace any leaky sealings.
8.2.1 Replacing the o-ring
The sealing washer has two sides. The concave side must point to the o-ring.
1. Insert the first o-ring.
2. Press the o-ring down with the universal
capillary holder.
3. Insert the second o-ring and press it
down.
4. Insert the sealing washer and press it on
the o-ring.
1 O-ring
2 Adapter
3 Removal tool
1. Remove the Femtotips by turning them.
2. Extract the o-ring with the removal tool.
3
1 2
