Maintenance
FemtoJet ® 4i
English (EN)
41
8 Maintenance
8.1 Replacing the sealings in the grip head
You must replace any damaged o-rings.
8.1.1 Removing the sealing washer and o-rings
Extract the sealing washer and the o-rings with the hook of the removal tool.
1 Sealing washer
2 O-rings
3 Grip head with sealing washers and
o-rings
4 Removal tool
1. Extract the sealing washer.
2. Extract the two o-rings consecutively.
The second sealing washer remains in
the grip head.
1
2
4
3
