Installation
FemtoJet
® 4i
English (EN)
22
4.4.3 Connecting two devices
Prerequisites
• Y-cable FJ4 is available.
• Devices are switched off.
Two devices can be connected with the Y-cable FJ4.
The following combinations are possible:
• Computer
• Micromanipulator
1. Connect the Y-cable to the MANIPULATOR port.
2. Connect the computer to the Y-cable.
3. Connect the micromanipulator to the Y-cable.
4. Switch on the Microinjector.
The initialization phase starts.
After completion of the initialization phase, the main screen appears.
4.5 Connecting accessories
It is possible to connect the following accessories to the Microinjector:
• Foot control or
• Hand control
4.5.1 Connecting a foot control
Prerequisites
• The Microinjector is switched off.
1. Connect the foot control to the FOOT SWITCH port.
4.5.2 Connecting a hand control
Prerequisites
• The Microinjector is switched off.
• No foot control has been connected.

Connect the hand control to the FOOT SWITCH port.
Control with a PC is described in the Cell Technology · PC Control manual.
The operation is described in the manual for the micromanipulator.
The hand control is not included in the delivery package and must be ordered
separately.
