10. DAILY INSPECTION & MAINTENANCE
10 - 12 P/N 0112478
PLACARDS AND DECALS INSPECTION CHART II
NO PART # DESCRIPTION REQ
20 0070418 Snorkelift logo 3
21 0323896 Danger - electrocution hazard 5
22 0073298 Danger - foam/solid tires 2
23 0073585 Made in USA 2
24 0071925
0071926
Gasoline fuel (gasoline units
only)
Diesel fuel (diesel units only)
1
1
25 0191390 PRO100 logo 2
26 0191491 Danger - EMS tampering 1
27 0071927 Hydraulic oil 2
28 0070540 Yellow arrow 3
29 0073491 Safe operation information 1
30 0070541 Blue arrow 3
31 0070901 Caution - serial number 1
32 0323897 Danger - you must not operate 1
33 0190988 Danger - ground control
instructions 1
34 0191173 EMS ground operation 1
35 0190937 Rear door (white stripe) 1
36 7030003 Lube recommendations 1
37 0151410 Danger - rotating engine parts 2
38 451986 Danger - do not alter limit
switch 1
39 0070921 125 volt 20 amp 1
40 0323899 Danger - electrocution hazard 1
41 0110708 Danger - axles/jack 1
42 0073492 Rotate while greasing 2
43 7050004 Record pouch 1
44 0181562 ANSI A92.5-1992 1
45 0191244 Ground control symbol
definition 1
46 0190992 Emergency bleed down 2
47 0190995 Danger - emergency bleed
down procedure 1
48 0190999 EMS status 1
49 0073224 Notice manual re-order 1
50 0073043 Manual holder 1
51 0111623 Engine protection system 1
52 0191174 EMS lights 1
53 0191137 Ground controls 1
54 0072276 Lug nut torque 450-500ft lb 4
55 0191236 EMS circuit breaker location 1
56 0073089 Battery disconnect switch 1
OPTIONAL PLACARDS AND DECALS
NO PART # DESCRIPTION REQ
N 0081441 Caution - liquid withdrawal
(dual fuel & LP only option) 1
P 0090492 Dual fuel switch (dual fuel
option) 1
R 0191435 Warm-up at ground (hydraulic
warm-up option) 1
S 0082203 Danger - crushing hazard (tow
package option) 1
T 0111343 High range speed selector
valve (4x4 units only) 1
U 0071793 Hydraulic warm-up system
instructions (hydraulic warm-
up option) 1
V 0090493 Dual fuel instructions (dual fuel
options) 1
W 0082160 Danger - towing hazard (tow
package option) 1
X 0073080 Cold start (cold start option) 1
Y 0090760 Steering float valve (tow
package option) 1
Z 0082171 Towing instructions (tow
package option) 2
