10. DAILY INSPECTION & MAINTENANCE
10 - 10 P/N 0112478
23. Placards and decals
Look to see that all placards and decals are in place and legible. Replace any missing or illegible
placards or decals before placing the TB100J into service for the daily work shift.
The OPTIONAL PLACARDS AND DECALS, listed below on this page, are only installed on machines
that have the corresponding options.
Placard and decal kits for the TB100J are available from Snorkel dealers.
PLACARDS AND DECALS INSPECTION CHART I
NO PART # DESCRIPTION REQ
1 0073667 Inspect wire ropes 2
2 0190989 Danger - do not reach through
holes 3
3 969449 Stripe 22 inches long
4 0323899 Danger - electrocution hazard 2
5 0073668 Caution - do not use boom to
lift 1
6 0072531 Danger - electrocution hazard 1
7 0070921 125 volt 20 amp 1
8 0071425 Platform identification 1
9 0074311 Danger - cylinder failure 8
10 0070418 Snorkelift logo 2
11 0191139 Danger - platform control box
top 1
12 0191245 Platform control symbol
definition 1
13 0150448 Attach fall restraint 1
14 0190992 Emergency bleed down 2
15 0191150 Platform control box front 1
16 0191138 Platform control box top 1
17 0190994 Danger - emergency bleed
down Procedure 1
OPTIONAL PLACARDS AND DECALS
NO PART # DESCRIPTION REQ
A 0111342 High range speed selector
location (4x4 units only) 1
B 0181376 Lights on/off switch (head/tail
light option) 1
C 0191030 Machine/generator (hydraulic
AC generator option) 1
D 0191436 Warm-up at platform
(hydraulic warm-up option) 1
E 0191251 Danger - platform slide
controls (8ft aluminum self
stow platform option) 1
F 0090589 Platform capacity 500 (8ft steel
non-stow platform option or 8ft
aluminum self stow platform
option) 1
G 0110492 Platform capacity 600 (8ft
aluminum or 5ft steel non-stow
platform option) 1
H 0073085 Platform capacity 650 (5ft
aluminum non-stow platform
option) 1
J 0181571 Fuel empty (fuel empty
indicator option) 1
K 0191253 Platform slide interlock switch
(8ft aluminum self stow
platform option) 1
L 0082164 Danger - do not ride platform
(towing option) 1
M 0191252 Platform latches (8ft aluminum
self stowing platform option) 2
