3. SPECIFICATIONS
1 3 - P/N 0112478
The TB100J is a boom-supported elevating
work-platform built to conform to the following
standards:
OSHA Paragraph 1910.67 Title 29,
C.F.R.Vehicle-Mounted Elevating and Rotating
Work Platforms - Labor.
OSHA Paragraph 1926.556 Title 29, C.F.R.,
Aerial Lifts - Construction.
ANSI Standard A92.5-1992 Boom-Supported
Elevating Work Platforms.
T
GENERAL SPECIFICATIONS
Working height (nominal) .....106 ft - 0 in (32.3 m)
Platform height (maximum) ..100 ft - 0 in (30.5 m)
Platform reach (maximum).....66 ft - 0 in (20.1 m)
Length
(booms down and retracted)...44 ft - 6 in (13.6 m)
Width:
axles retracted .........................8 ft - 6 in (2.6 m)
axles extended.....................12 ft - 10 in (3.9 m)
Height (booms down) ...............10 ft - 4 in (3.1 m)
Wheelbase...............................12 ft - 0 in (3.7 m)
Ground clearance ............................17 in (0.3 m)
Weight (approximate)....... 33,000 lbs (15,000 kg)
Max. single wheel load ....... 16,750 lbs (7,598 kg)
Ground pressure (max.) ............. 74 psi (511 kPa)
Travel speeds (max.):
booms down and retracted
high speed, low torque .....3.0 mph (4.8 km/hr)
high torque, low speed ...0.75 mph (1.2 km/hr)
booms up and/or extended
to mid elevation ..............0.75 mph (1.2 km/hr)
above mid elevation................................ creep
Gradeability...................................................25%
Turning radius:
outside ..................................30 ft - 0 in (9.1 m )
inside, axles retracted ............18 ft - 8 in (5.7 m)
inside, axles extended ...........16 ft - 6 in (5.0 m)
Tires (foam filled) .. 15 x 22.5 in (38 X 57 cm) , 18 ply
Electrical system ... 12 V dc (neg. chassis ground)
Environmental operating ranges:
ambient air temperature .............. 0°F to +110°F
(-18°C to +43°C)
wind speed
(maximum gust or steady) .... 28 mph (45 km/hr)
Fuel tank capacity:
std. gasoline/diesel ........ 40 gal USA (151 liters)
optional LPG..................... 43.5 lbs USA (20 kg)
Hydraulic oil:
tank capacity ................. 60 gal USA (227 liters)
maximum temperature (at tank)... 200°F (93°C)
system capacity ............. 90 gal USA (341 liters)
maximum pressure ........ 2,800 psi (19,320 kPa)
Hydraulic oil recommended:
above 10
°F (-13°C) Mobil DTE 13M (ISO VG32)
below 10
°F (-13°C) Mobil DTE 11M (ISO VG15)
Boom elevation ...................+74°/-1° to horizontal
Boom movement times (complete range of
movement):
Jib Boom
UP ..........................................40 - 45 seconds
DOWN ...................................40 - 45 seconds
Turntable Swing
360
° CW or CCW,
boom retracted................. 110 - 120 seconds
boom extended ................ 320 - 330 seconds
Platform Rotation
180
° CW or CCW,..................16 - 20 seconds
Main Boom Elevation
UP (boom retracted).............80 - 120 seconds
UP (boom extended) ........... 120 -180 seconds
DOWN (boom retracted) .....80 - 120 seconds
DOWN (boom extended)..... 120 -180 seconds
Boom Extension
OUT .....................................90 - 120 seconds
IN .........................................90 - 120 seconds
3. SPECIFICATIONS
T
PLATFORM SPECIFICATIONS
PLATFORM
SIZE
inches (cm)
Unrestricted rated work load (total weight of personnel, tools, and
materials that the platform is designed to carry above its floor --
same as UNRESTRICTED PLATFORM CAPACITY)
standard aluminum 30 x 92 (76 x 234) Rated work load: 600 lbs (272 kg). Rated number of occupants: 3.
optional aluminum 30 x 60 (76 x 152) Rated work load: 650 lbs (293 kg). Rated number of occupants: 3.
optional self-stowing
aluminum 30 x 92 (76 x 234) Rated work load: 500 lbs (227 kg). Rated number of occupants: 2.
optional steel 30 x 60 (76 x 152) Rated work load: 600 lbs (272 kg). Rated number of occupants: 3.
optional steel 30 x 92 (76 x 234) Rated work load: 500 lbs (227 kg). Rated number of occupants: 2.
