7. OPERATION

7 -

P/N 0112478

8. Put on your fall restraint, enter the platform,
close the gravity gate, and attach the lanyard of
your fall restraint to the anchorage point (7).

9. At the platform-control box (8) set the
following:

EMERGENCY STOP (9) ..............pulled out
ENGINE THROTTLE (10) ............LO
DRIVE RANGE (11).....................LO

NOTE: With these settings the maximum
ground speed is 0.75 mph (1.2 km/hr). If you
want to go faster, see the "PLATFORM-
CONTROL BOX" section in the "CONTROLS"
chapter. Pay particular attention to the DRIVE
RANGE Table in that section.

10. Check the platform-control box circuit
breakers (12) to see that none has popped out.

1 2

1 0

Starting (from the platform)
Do not attempt to start a TB100J until the actions
in the previous part of this section (STARTING
FROM THE PLATFORM CONTROL BOX) have
been completed.

1. Turn the ANTI-RESTART MASTER SWITCH
(1) to ON and pause there a few seconds while
an alarm sounds to alert others that the TB100J
is about to start.

NOTE: If you pause 30 seconds or more an
automatic protection feature will prevent the
TB100J from starting. If that happens, turn the
ANTI-RESTART MASTER SWITCH to OFF
and try again.

C A U TIO N

If the engine fails to start (at the next step) in 20
seconds, turn the ANTI-RESTART MASTER
SWITCH to OFF and wait 60 seconds before
turning the switch to START again.

2. Turn the ANTI-RESTART MASTER SWITCH
(2) to START and hold it there until the engine
starts (or for a maximum of 20 seconds) then
release the switch to ON.

NOTE: Do not step on the foot switch while
you are trying to start the engine.

The engine should now be running.
