3. SPECIFICATIONS
3 3 - P/N 0112478
T
OVERALL DIMENSIONS
1 2 '-1 0 "
(3 .9 m )
A X L E S E X T E N D E D
8 '-6 "
(2 .6 m )
A X L E S R E T R A C T E D
5 '-.4 4 "
(1 .5 m )
1 0 '-4 "
(3 .2 m )
1 0 '-9 .5 "
(3 .3 m )
1 '-5 "
(0 .3 m )
9 '-3 "
(2 .8 m )
3 3 '-8 .5 "
(1 0 .3 m )
4 4 '-6 .4 "
(1 3 .6 m )
C E N T E R O F R O TAT IO N
& C E N T E R O F G R AV IT Y
IN S T O W E D P O S IT IO N
6 '-9 "
(2 .1 m )
1 2 '-0 "
(3 .7 m )
1 '-6 .3 "
(0 .5 m )
5 7 .5 "
(1 4 6 c m )
5 7 .5 "
(1 4 6 c m )
