Page 62
Cab and Covers
4-2
944E-42
4.1
OPERATOR’S CAB AND COVERS
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the machine cab and
covers. The following illustration identifies the
components that are referred to throughout this section.
MU6262
TRANSMISSION
CONTROL LEVER
STEERING
WHEEL
MIRROR
ACCELERATOR
PEDAL
SERVICE BRAKE
PEDAL
OPERATOR’S CAB
HOOD
OPTIONAL
SINGLE
JOYSTICK
SEAT
FRAME SWAY
JOYSTICK
BOOM LIFT/LOWER,
EXTEND/RETRACT
JOYSTICK
ATTACHMENT TILT &
TRANSFER CARRIAGE
JOYSTICK AND AUXILIARY
HYDRAULIC BUTTON
