Page 205
9-47
944E-42
Electrical System
2113
52
16
Amber
Coolant Temperature
Coolant Temperature 2 - Data Valid but Above
Normal Operational Range - Moderately Severe
Level
2114
52
0
Red
Coolant Temperature
Coolant Temperature 2 - Data Valid but Above
Normal Operational Range - Most Severe Level
2115
2981
3
Amber
Coolant Pressure
Coolant Pressure 2 Circuit - Voltage Above
Normal, or Shorted to High Source
2116
2981
4
Amber
Coolant Pressure
AEB15.60 Page 153 of 157 Coolant Pressure 2
Circuit - Voltage Below Normal, or Shorted to
Low Source
2117
2981
18
Amber
Coolant Pressure
Coolant Pressure 2 - Data Valid but Below
Normal Operational Range - Moderately Severe
Level
2182
1072
3
Amber
Engine Brake Output
#1
Engine Brake Actuator Driver 1 Circuit - Voltage
Above Normal, or Shorted to High Source
2183
1072
4
Amber
Engine Brake Output
#1
Engine Brake Actuator Driver 1 Circuit - Voltage
Below Normal, or Shorted to Low Source
2185
3512
3
Amber
System Diagnostic
code #1
Sensor Supply Voltage #4 Circuit - Voltage
Above Normal, or Shorted to High Source
2186
3512
4
Amber
System Diagnostic
code #1
Sensor Supply Voltage #4 Circuit - Voltage
Below Normal, or Shorted to Low Source
2195
703
14
Red
Auxiliary Equipment
Sensor
Auxiliary Equipment Sensor Input 3 Engine
Protection Critical - Special Instructions
2215
94
18
Amber
Fuel Delivery
Pressure
Fuel Pump Delivery Pressure - Data Valid but
Below Normal Operational Range - Moderately
Severe Level
2216
94
1
Amber
Fuel Delivery
Pressure
Fuel Pump Delivery Pressure - Data Valid but
Above Normal Operational Range - Moderately
Severe Level
2217
630
31
Amber
Calibration Memory
ECM Program Memory (RAM) Corruption -
Condition Exists
2249
157
1
Amber
Injector Metering
Rail 1 Pressure
Injector Metering Rail 1 Pressure - Data Valid
but Below Normal Operational Range - Most
Severe Level
2261
94
15
Maint
Fuel Delivery
Pressure
Fuel Pump Delivery Pressure - Data Valid but
Above Normal Operational Range - Least
Severe Level
2262
94
17
Maint
Fuel Delivery
Pressure
Fuel Pump Delivery Pressure - Data Valid but
Below Normal Operational Range - Least
Severe Level
Fault
Codes
SPN
Codes
FMI
Codes
Lamp
Color
SPN Description
Cummins Description
