2-11 944E-42
General Information and Specifications
2.3 SPECIFICATIONS
2.3.1 Travel Speeds
2.3.2 Hydraulic Cylinder Performance
Note: Machine with no attachment or load, engine at full throttle, hydraulic oil above 130° F (54° C) minimum, engine
at operating temperature.
2.3.3 Electrical System
First Gear 3.5 mph (5,6 km/hr)
Second Gear 6 mph (9,7 km/hr)
Third Gear 14 mph (23 km/hr)
Fourth Gear 20 mph (32 km/hr)
Function Approximate Times, in Seconds
Boom Extend (boom level) 11 to 15
Boom Retract (boom level) 13 to 17
Boom Lift (boom retracted) 11 to 15
Boom Lower (boom retracted) 11 to 15
Quick Attach Tilt Up 2.5 to 3.5
Quick Attach Tilt Down 3 to 5
Transfer Carriage Forward (boom retracted and level) 9 to 14
Transfer Carriage Rearward (boom retracted and level) 9 to 13
Frame Sway Left to Right (boom retracted and level) 9 to 11
Frame Sway Left to Right
(boom retracted, raised above 40
° and emergency brake engaged)
26 to 30
Frame Sway Right to Left (boom retracted and level) 9 to 11
Frame Sway Right to Left
(boom retracted, raised above 40
° and emergency brake engaged)
26 to 30
Battery
Type, Rating 12 VDC, Negative (-) Ground, Maintenance Free
Quantity 2
Reserve Capacity 850 Cold Cranking Amps @ 0° F (-18° C)
Group/Series Group 27
Alternator 12V, 100 Amps
