Hydraulic System
8-42
944E-42
h. Swing Carriage Cylinder (optional)
i.
Side Tilt Carriage Cylinder (optional)
Piston
Set Screw
Head
Valves
440-500 lb-ft (597-678 Nm)
85-95 lb-ft (115-129 Nm)
250-300 lb-ft (339-407 Nm)
30-35 lb-ft (41-47 Nm)
Locknut
Head
Valve
550-650 lb-ft (745-881 Nm)
300-400 lb-ft (407-542 Nm)
30-35 lb-ft (41-47 Nm)
