Page 46 Engine Data Management
Initially Entering the Tank Capacity
To initialize or change the tank capacities, hold the STEP button while
turning on the power to the EDM. The following program steps will be
displayed:
Tap STEP
to advance
Tap the LF button to sequence
through these values Comments
MAIN=50 MAIN=0 …MAIN=999 Main tank capacity, in
units selected
AUX? N AUX? NAUX? Y Y—Yes—aircraft has
auxiliary tanks
AUX=0 AUX=0 …AUX=250 Auxiliary tank capacity
Navigation Data Formats
Output of any GPS; input to EDM. The EDM automatically configures
itself for one of three industry standard data formats:
Set handheld
GPS to output MEA-183.
Format Baud rate
NMEA-183
(Marine Nav
Data Format) 4,800 This is the format for most handheld GPS receivers.
Loran must have sentences RMA & RMB. GPS must
have sentences RMB & RMC.
Aviation Data
Format 9,600 “Output sentence type 1” Required sentences are: A, B,
C, D, E, I and L first character identifier byte. Sentence
terminator may be either or alone.
Northstar
binary 1,200 M1 setup select “NO EXTENDED”, “NAV ONLY”
GPS-C Fuel Flow Format for GPS Bi-directional Comm
GPS-C Input to GPS; output of EDM
0 No fuel data output
1 Garmin (Shadin Miniflow format)
2 Allied Signal (format B) “To waypoint only”
3 Arnav/EI fuel data
4 Allied Signal (format C) *
5 (Not used)
6 Garmin 430/530 GNX-80/GX-60 “To waypoint only”
7 Garmin 430/530 GNX-80/GX-60 “To Destination only”
8 Allied Signal (format B) “To Destination only”
