For Your Safe Flight Page 29
Select
Switch
Parameter
Description Example Comments
T, A Voltage, System Bus I4.2BAT Battery voltage
T, A Outside Air
Temperature 8I OAT °F or °C
T, A Induction Air
Temperature I25 IAT Out of intercooler
T, A Compressor
Discharge
Temperature 300 CDT Into intercooler
T, A Carburetor
Temperature -22 CRB Not available when CDT is
installed
T, A Difference between
hottest and coldest
EGT 80 DIF Dot indicates most widely
deviating cylinder
T,A,F RPM MAP for 1 sec 2450 23.I RPM and Manifold pressure
F, A Fuel Remaining 37.2 REM In gallons, liters or pounds or
kilograms
F, A Fuel required to
next GPS WPT or
Destination 25.9 REQ Present with GPS interface
Valid signal and way point
F, A Fuel Reserve at next
GPS WPT or
Destination I I.3 RES Present with GPS interface
Valid signal and way point
F, A Nautical Miles per
Gal I3.0 MPG Present with GPS interface and
valid signal or MPK, MPL, MPP
F, A Time to Empty 02.45H.M. Hours. Minutes Remaining at
current fuel burn
F, A Fuel Flow Rate I3.5 GPH Or KPH, LPH,PPH
F, A Total Fuel Used 38 USD Since last refueling or trip total.
T, A EGT, CHT I340 376 EGT, left, CHT, right. Dot
indicates cylinder
T, A TIT, Turbine Inlet
Temperature I370 I3.5 Turbine #1, left and fuel flow
right
T, A Oil Temperature I 78 OIL
T, A Shock Cooling -30 CLD Dot indicates fastest cooling
cylinder
