InsTallaTIon of Wall Panels (conTInUeD)
Backlapping the wall panels 1 foot or 2 foot is routinely done to match panel coverage with the
building width and length . On the sidewall this is done with the last panel installed . On the endwall
this is normally done near the center and will be marked on the erection drawings .
sidewall
endwall
2'-0"
2'-0"
1'-0"
1'-0"
