Wall InsUlaTIon (conTInUeD)
The first run of wall insulation should be installed so that its forward edge is just ahead of the
leading edge of the wall panel . This keeps the forward edge of the insulation ahead of the wall
panel for joining the next blanket .
Wood
Blocking
Blanket
Insulation
Wall Panel
Wood
Block
Clamping
Pliers
Vapor Barrier
Attach base angle with
double sided tape
Cut Fiberglass
from Vapor
Barrier and
fold barrier up
Eave
Strut
noTe: Do not allow the insulation to wick moisture from the floor.
WaRnInG! Insulation has no load bearing strength. Do not lean or prop material
against wall insulation. observe all proper safety procedures when handling
fiberglass insulation, such as dust masks, gloves and long sleeved shirts, to
minimize contact with the insulation.
