10-7
6036, 6042, 8042, 10042, 10054
Stabil-TRAK™
System and Boom Interlock System
10.5
STABIL-TRAK SYSTEM TEST
Note: The operator must know that the Stabil-TRAK
system is active and functioning properly.
To test the function of the Stabil-TRAK system, read the
Stabil-TRAK System Test instructions and follow Steps 1
through 9 of Section 10.5.2, “Stabil-TRAK System Test
Procedures.”
10.5.1
Stabil-TRAK System Test Instructions
• Test the Stabil-TRAK system with the machine
on a level surface.
• Remove any attachment from the quick attach
before performing the test.
• DO NOT extend the boom at any time during the
test. Perform the test with the boom fully retracted.
• DO NOT raise the boom above 60° for Steps 3-6.
• DO NOT raise the boom above 45° for Steps 7-9.
• Follow Steps 1 through 9 of the Stabil-TRAK
system test procedure exactly as written.
Note: If the Stabil-TRAK light goes OFF and the front
left tire lowers to the ground at any time during Steps 4
through 7, the test was not performed properly or the
Stabil-TRAK system is not functioning properly. Carefully
repeat the steps starting with Step 1.
If the Stabil-TRAK light goes OFF and the front left tire
lowers to the ground consistently during Steps 4 through 7,
the Stabil-TRAK system is not functioning properly and
the test should be stopped immediately. If the Stabil-
TRAK system is not functioning properly, follow the
procedures in Section 10.8, “Stabil-TRAK Hydraulic
Circuit Operation and Troubleshooting,” to repair the
system.
10.5.2
Stabil-TRAK System Test Procedures
If Steps 1 through 9 prove positive, the Stabil-TRAK
system is functioning properly, and the machine can be
returned to service. If any of these steps indicate that the
Stabil-TRAK system is not functioning properly, follow the
procedures in Section 10.8, “Stabil-TRAK Hydraulic Circuit
Operation and Troubleshooting,” to repair the system.
