Page 216

Stabil-TRAK™
System and Boom Interlock System
10-2
6036, 6042, 8042, 10042, 10054
10.1
STABIL-TRAK SYSTEM
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the Stabil-TRAK
system. The following illustration identifies the
components that are referred to throughout this section.
MH2962
BOOM PROXIMITY
SWITCH
FRAME SWAY
CYLINDER
STABIL-TRAK
CYLINDER
STABIL-TRAK MANIFOLD
MODEL 10054 SHOWN
