Page 106

Axles, Drive Shafts, Wheels and Tires
5-2
6036, 6042, 8042, 10042, 10054
5.1
AXLE, DRIVE SHAFT AND WHEEL
COMPONENT TERMINOLOGY
(6036 & 6042)
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the axles, drive shafts,
wheels and tires. The following illustration identifies the
components that are referred to throughout this section.
MA9181
FRONT AXLE
ASSEMBLY
FRONT
STEERING
CYLINDER
FRONT DRIVE SHAFT
REAR DRIVE SHAFT
REAR STEERING
CYLINDER
REAR AXLE
ASSEMBLY
STABILIZER
CYLINDER
(6042 ONLY)
ENGINE-TO-TRANSMISSION
DRIVE SHAFT
FRAME
SWAY
CYLINDER
