Bosch VMD01 M60 NTSC User Manual
Page 92
– 92 –
A1 February 03/Trb
Voortzetting montage
Nederlands
2.2
19”-inbouwframe en bekabeling
(accessoire VMD–RA90)
maximale uitbreiding
8 apparaten
Montagebeugel
Voorzijde
Netadapter
Achterzijde
L
N
EG
+5V
–5V
100 – 240V
Netadapter
Zwenkrichting
+5V
100 – 240V
Si = 2A
Bovenaanzicht (verdeler LP)
Voor montage in de eenheid de montagebeugel (verpakking) plaatsen, in de
eenheid zetten, vastschroeven en de bekabeling doorvoeren.
Let op
De aarding moet deskundig conform IEN 60950 worden uitgevoerd.
2.2.1
19”-inbouwframe zonder bekabeling (accessoire VMD–RA00)
Het frame wordt geleverd zonder netadapter/kabelset/verdeler-LP, met
blindplaat.
