– 8 – A1 February 03/Trb
3 Functions
English
3.1 Overlaid lines for color and B/W signals
Color Black/White
Alarm object: Striped line with high contrast Red
Pre-alarm object: Yellow Striped line with low contrast
Tracking line: Green Striped line
Color Black/White
Area of sensitivity: Striped line Green
Perspective: Green: Foreground
Blue: Background
Striped lines;
Foreground square: Larger dotted line
Background square: Smaller dotted line
Directionality: Striped lines;
Directional arrow with smaller dotted lines
Tolerance lines with larger dotted lines Green: Direction
Blue: Tolerance
Configuration
Live and archived images
3.2 Rotary switch
Operation Function
Briefly press
Briefly press again
Rotate right
Alarm image memory on
Alarm image memory off
Rotate left Backwards in alarm archive (–)
Forwards in alarm archive (+)
Long press (> 2 sec.) Acknowledge alarm
3.3 Light emitting diodes
LED Status
off
on
L2 red
(when L1 on)
L1 green
Blinking
off
on
Blinking
L2 red
(when L1 blinking)
off
Function
No supply of power to unit
Unit operating normally
Unit malfunction as combined message
Unit defective and/or video channel malfunction
No alarm, not armed
No alarm, armed
Object detected/Alarm on
No malfunction on video signal,
unit malfunctioning
on No video signal, no general unit malfunction
Blinking
Video signal interference:
1. Signal/Noise ratio too low
2. Camera blinded
3. Scene lighting level too low
