– 12 – A1 February 03/Trb
Programming, continued English
5.2 Programming
Starting programming
Parameter set 1 or = Parameter set 2
5.2.1 Alarm set 1 or 2
Operating type
Automatic acknowledgement, live image on alarm
Manual acknowledgement, live image on alarm
Manual acknowledgement, alarm image on alarm
See also chapter 6
Alarm contacts (contact output I see 3.4)
Continuous signal during object detection
Impulse on new object detection
Periodic signal during object detection
Signaling of alarms
Automatic
acknowl-
edgement
LED red
Blinking
Relay II
Output
contacts
As long
as
object
detected
As long
as
object
detected
As long
as
Alarm
on
As long
as
Alarm
on
As long as
object
detected
or impulse
As long as
object
detected
or impulse
Manual
acknowl-
edgement
