Some headsets come in two parts, a remote control
unit and headphones. A remote control unit has a
microphone and keys to answer or end a phone call,
adjust the volume, and play music or video files. To use
the headphones with a remote control unit, connect
the unit to the Nokia AV Connector in the device, then
connect the headphones to the unit.
Warning: When you use the
headset, your ability to hear outside
sounds may be affected. Do not use
the headset where it can endanger
your safety.
Do not connect products that create
an output signal as this may cause
damage to the device. Do not connect
any voltage source to the Nokia AV
Connector.
When connecting any external device
or any headset, other than those
approved by Nokia for use with this device, to the Nokia
AV Connector, pay special attention to volume levels.
Attach wrist strap
1. Open the back cover.
2. Thread a wrist strap, and
tighten it.
3. Close the back cover.
Antenna locations
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while
the antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
1 — Bluetooth and wireless LAN (WLAN), and GPS
antennas
2 — FM transmitter antenna
3 — Cellular antenna
The FM transmitter antenna is located in the back cover
of your device. If you change the back cover, check that
the new cover includes this antenna, otherwise this
16
Get started
