When installing the microphone on the steering column
1. Install the microphone on the microphone clip.
2. Install the microphone clip on the steering column.
• It is extremely dangerous to allow the microphone lead to become wound
around the steering column or gearstick. Be sure to install the unit in such a
way that it will not obstruct driving.
Adjusting the microphone angle
The microphone angle can be adjusted by moving forward or backward the microphone
clip angle.
Clamps
Use clamps to secure the
lead where necessary
inside the vehicle.
Double-sided tape
Install the microphone clip on
the rear side of the steering
column.
Fit the microphone lead
into the groove.
Microphone
Microphone clip
