Before using this machine 1
C550 1-6
2
Note
The display positions of the [Address Book], [Direct Input], [Job History]
and [Address Search] tabs differ depending on the settings specified for
the Scan/Fax Settings parameters in Utility mode. For details, refer to
“Setting the initial state of Fax/Scan screen (Scan/Fax Settings)” on
page 10-19.
No. Name Description
1 [Check Job] button Displays a list of selected destinations in the left panel of
the screen.
2 [Job List] button Displays a list of jobs being executed and a list of pending
jobs in the left panel of the screen.
3 [Address Book] tab Displays a screen for selecting a registered destination.
(page 2-17)
4 Message display area Displays machine status and operating procedures that
need to be carried out at that time.
5 [Direct Input] tab Displays a screen for entering destinations directly.
(page 2-23)
6 [Job History] tab Displays a screen for selecting destinations from the Job
History. (page 2-25)
7 [Address Search] tab Displays a screen for searching for destinations on the
LDAP Server. (page 2-26, page 2-28)
8 No. of destinations Displays the no. of destinations specified.
9 [Off-Hook] button This is touched for manual transmission or reception.
(page 2-47, page 3-4)
When this button is touched the telephone line tone is
heard through the speaker.
10 Setting area This area is for setting destinations and functions.
11 [Communication Settings]
button Displays a menu for line settings and settings concerning
timer transmissions and communications in general.
(page 6-5)
12 [Original Settings] button Displays a menu for original-related settings such as
mixed original and Binding Position. (page 6-4)
13 [Scan Settings] button Displays a menu for settings concerning the scanning
process, such as original image quality and resolution.
(page 2-12, page 6-2)
14 Remaining memory Displays the amount of memory remaining during opera-
tion.
15 Remaining toner Displays the amount of toner remaining.
16 Left panel Displays the job list and destination list.
17 Destination display section Displays the destination specified.
