C/146000, C/146100, C/146200

3/10

N/us 1.6.009.028

Our policy is one of continued research and development. We therefore reserve the right to amend,

without notice, the specifications given in this document.

Spares Kits for cylinders
with NPT ports and stroke
in inches

1

2

5

6

8

3

4

7 & 9

10

For C/146000. .../M. C/146200. .../M Internally and Roller guided models

Ø

Type

NPT spares kit

Spares kit w/seal

Comprising

Seal strip

Cover strip

and cover strip

Item

Description

Quantity

Item 2

Item 3

20

C/146020..../M

QM/146020/00

QC/146020/88/*

C/P 40262/*

C/P 74223/*

25

C/146025..../M. C/146225..../M

QM/146025/00

QC/146025/88/*

C/P 40262/*

C/P 74131/*

32

C/146032..../M. C/146232..../M

QM/146032/00

QC/146032/88/*

C/P 40344/*

C/P73936/*

40

C/146040..../M. C/146240..../M

QM/146040/00

QC/146040/88/*

C/P 40263/*

C/P73945/*

50

C/146050..../M. C/146250..../M

QM/146050/00

QC/146050/88/*

C/P 40626/*

C/P73946/*

63

C/146063..../M. C/146263..../M

QM/146063/00

QC/146063/88/*

C/P 40626/*

C/P73946/*

80

C/146080..../M

QM/146080/00

QC/146080/88/*

C/P 40715/*

C/P 74232/*

1

Clamping lever (ø 25 ... 63)

2

2 + 3

Seal-/cover strip

1

4 + 5

O-ring

2

6

Seal

2

8

Seal

2

10

Wiper

1

Grease

1

* Insert stroke length in inches
Note: Please quote the cylinder type number when ordering spare parts

For C/146100. .../M Externally guided models

Ø

Type

NPT spares kit

Spares kit w/seal

Comprising

Seal strip

Cover strip

and cover strip

Item

Description

Quantity

Item 2

Item 3

20

C/146120..../M

QM/146120/00

QC/146120/88/*

C/P 40262/*

C/P 74223/*

25

C/146125..../M

QM1/46125/00

QC/146125/88/*

C/P 40262/*

C/P 74131/*

32

C/146132..../M

QM/146132/00

QC/146132/88/*

C/P 40344/*

C/P73936/*

40

C/146140..../M

QM/146140/00

QC/146140/88/*

C/P 40263/*

C/P73945/*

50

C/146150..../M

QM/146150/00

QC/146150/88/*

C/P 40626/*

C/P73946/*

63

C/146163..../M.

QM/146163/00

QC/146163/88/*

C/P 40626/*

C/P 73946/*

80

C/146180..../M

QM/146180/00

QC/146180/88/*

C/P 40715/*

C/P 74232/*

1

Clamping lever (ø 25 ... 63)

2

2 + 3

Seal-/cover strip

1

4 + 5

O-ring

2

6

Seal

2

7

Guide bar

4

8

Seal

2

9

Felt

2

10

Wiper

1

Grease

1

* Insert stroke length in inches
Note: Please quote the cylinder type number when ordering spare parts

Internal

External

Roller
