N/us 1.6.009.021

C/146000, C/146100, C/146200

3/10

Our policy is one of continued research and development. We therefore reserve the right to amend,

without notice, the specifications given in this document.

KE

KF

C/146100/F1 – cylinder with linear sensor and external adjustable guide

C/146200/F1 – cylinder with linear sensor and precision roller guide

Type

Ø

KA

KB

KC

KD

KE

KF

C/146.32/F1/...

32

1.73

1.57

2.03

1.99

2.20

2.22

(44)

(40)

(51.5)

(50.5)

(56)

(56.5)

C/146.40/F1/...

40

2.91

1.81

2.26

2.22

2.52

2.46

(74)

(46)

(57.5)

(56.5)

(64)

(62.5)

C/146.50/F1/...

50

4.09

2.13

2.58

2.70

2.95

2.76

(104)

(54)

(65.5)

(68.5)

(75)

(70)

C/146.63/F1/...

63

5.47

2.40

2.83

2.66

3.13

2.74

(139)

(61)

(72)

(67.5)

(79.5)

(69.5)

+

-

U

1 BN

2 WH

4 BK

3 BU

5 GY

1

4

3

2

5

Pin-

Colour

Function

No.

1

Brown

+

2

White

Program input

3

Blue

-

4

Black

Output +

5

Grey

Output -

Connector details

Electrical data of linear position sensor:

Operating voltage: 10 ... 30 V d.c.. resolution 16 bit.

Repeat accuracy 0.006 %. output 4 ... 20 mA. short-circuit protection

Linearity 0.05 % of measuring range. protection class IP67
